101 Series SS Actuator Threaded Angle Seat Valve

Design Specifications:

Advantages：

◎Compact structure,high circulation capacity.

◎Simple and quick debugging.

◎The valve stem automatically corrects (self-regulates), self-lubricates, and requires no maintenance.

◎Visible position indicator rod.

◎Extremely suitable for high-frequency switching and quantitative operations.

◎It has excellent adjustment characteristics.

◎The cylinder is made of stainless steel material, which performs exceptionally well in harsh environments, with modular accessory categories, 360° rotation capability, and low maintenance rate. Stainless steel material is particularly durable in steam and corrosive applications; reliable and sturdy sealing components ensure tight sealing and long lifespan.

◎Can be installed in any position (upward, flat, or tilted), with the cylinder standing upright being more suitable.
