Size: DN8-DN100 (1/4’’-4’’).
Connection Type: thread, welded, tri-clamp, flange, other methods for customized consultation.
Valve body: CF8, CF8M, SS316L, 2205
Seat seal: PTFE, RPTFE
Stem seal: PTFE,FKM,RPTFE
Piston seal: FKM,NBR
Nominal pressure (working pressure): 0-16bar (0-232Psi), vacuum as low as -0.9bar optional.
Outside temperature (environment): -10℃- 80℃.
Applicable media: water, neutral gas or liquid, alcohol, oil, fuel, steam, organic solvents, acid-base solutions, etc.
Medium temperature: -10℃- 180℃ (PTFE normal temperature type)
25℃- 220℃ (PTFE high temperature type)
Maximum viscosity: 600cst (mm²/s)
Valve leakage class: DIN EN 12266 Class A
Advantages：
- Compact structure, high flow capacity.
- Simple and fast adjustment.
- Ideal for high-frequency switching and quantitative operation.
- Excellent regulating characteristics.
- Can be installed in any position (upward, horizontal, or inclined), with the cylinder being more suitable in an upright position.
- Utilizes a bottom sealing structure for rapid cleaning and reduced residue.
- Flow adjustment cone can be added at the valve core for manual flow control.
