301 3-Way Tri-clamp Angle Seat Valve

Design Specifications:
Connection Type: Threaded, Quick Connect
Control Type: Single-acting normally closed, Double-acting normally closed, Double-acting free state
Valve Body: CF8, CF8M
Actuator: Stainless Steel
Seat Seal: PTFE
Nominal Pressure (Operating Pressure): 0-16 bar (0-232 psi)
Control Pressure: 3-8 bar
Control Medium: Clean compressed air, lubricated or dry other and neutral gases, inert gases ≤ 60°C
Ambient Temperature: -10°C to 80°C
Applicable Media: Water, neutral gases or liquids, alcohol, oil, fuel, steam, organic solvents, acidic or alkaline solutions, etc.
Media Temperature: -10°C to 180°C (PTFE normal temperature type)
Maximum Viscosity: 600 cst (mm2/s)
Valve Leakage Class: DIN EN 12266 Class A
