312 Series Pneumatic Tri-Clamp Manifold Valve

Design Specifications:
Operating Pressure : 0-16 bar (0-232 psi)
Control Pressure: 3-8 bar (43.5-116 psi)
Control Medium: Clean compressed air, lubricated or dry other and neutral gases,

                              inert gases ≤ 60°C
Seat Seal: PTFE
Valve Body: CF8, CF8M
Media: Water, oil, gas, etc.
Media Temperature: -10°C to 180°C
Ambient Temperature: -10°C to 80°C
Connection Type: Tri-clamp
Control Type: Single-acting normally closed, Double-acting normally closed,Double-acting free  state
Valve Leakage Class: DIN EN 12266 Class A
