410 Balance Valve

The 410 series balance valve is a type of remote control regulating valve. It regulates steam pressure to downstream pressure by using the air pressure provided through the remote control loading port. It can sensitively respond to minor pressure changes and is widely used in the vulcanization process of rubber products, tires, and other similar manufacturing processes.
Inquiry Download

Product Description

Technical Drawings

Design Specifications:

Operating Pressure: ≤1.3MPa
Operating Temperature: Up to 205℃
Valve Body Material: CF8
Bonnet Material: Carbon Steel or Stainless Steel CF8
Applicable Media: Steam
Control Mode: Normally Closed
Connection Type: Flange (JIS 20K/ASME CLASS300/DIN PN40)
