513 Filling Valve With Internal Sealing and Suction

Technical Specifications

Control type: Double-acting free state, double-acting normally closed

Working pressure: 0-7bar (0-102Psi)

Control media: Clean compressed air or neutral gas, temperature ≤60℃.

Control pressure: 3-4.5bar(44-65Psi)

Valve body material: CF8,CF8M

Sealing material: PTFE

Applicable media: Water, neutral gas or liquid, alcohol, oil, fuel, steam, organic solvents, acid and Acid-base solution, etc.

Medium temperature: -10℃~ 120℃

Ambient temperature: -10℃~ 80℃

Connection type: Threaded (BSP,BSPT,NPT)

Advantages

1.Ideal for filling machinery, particularly viscous and foamy liquids.

2.Fast, precise, and stable filling.

3.Compact design for easy pipe layout.

4.Special design prevents dripping during filling.

5.Chamfered structure guides and positions for submerged filling.

6.Internal suction pipe effectively recovers dripping liquid.
