505 Sauce Filling Valve With Internal Sealing

Technical Specification

Control type: Double acting

Operating pressure:0-7bar(0-102psi)

Control pressure: 3-4.5bar(44-65psi)

Control medium:CF8M

Seal material: PTFE

Medium temperature:-10℃- 120℃

Advantages

1. Widely used in filling machinery. Suitable for viscous, granular sauce filling. Such as beef sauce, chili sauce, bean paste, etc.
2. Fast, accurate and stable filling.
3. The internal structure adopts plunger design, resulting in easy cleaning and minimal residue.
4. The filling body and the connection are connected by tri-clamp, so that they can be installed, uninstalled, and adjusted easily.
5. Long valve stroke enables large-capacity filling.
6. Accessories, such as proximity switch and position indicator, can be installed on top of actuator to enable feedback of valve open/close state.
