Technical Specification
Nominal pressure: 0-16bar (0-232Psi)
Control pressure: 3-8bar(43.5-116Psi)
Control medium: Clean compressed air, neutral gas, temperature ≤60℃
Valve body Material: CF8,CF8M
Valve seat seal material: Fluororubber FKM / Ethylene Propylene Diene Monomer EPDM
Applicable medium: FKM is suitable for most media, except steam
EPDM is used for hot water and steam, not suitable for oils, fuels, etc.
Ambient temperature: -10℃~ 80℃
Medium temperature: -20℃~ 150℃(FKM) -20℃~ 130℃(EPDM)
Control type: Single action normally closed, normally open, double action normally closed, normally open, double action without spring
Connection type: Thread (BSP/BSP/NPT) Valve leakage level: DIN EN 12266 A level
Advantages
1.Compact, small-sized structure ideal for limited spaces. The valve body is stainless steel, offering a high-end look and corrosion resistance. The actuator and valve are integrated, simple, reliable, rigid, stable, and can be installed in any direction.
2.Fast speed, small stroke, completes opening/closing in less than 0.5 seconds with minimal pressure loss. The medium flow in the valve body is good due to minimal resistance interference, resulting in fast switching speed and low pressure loss.
3.Resistant to vacuum, excellent sealing performance, suitable for vacuum pipelines.
4.Pressure difference fluctuations before and after the valve do not affect the valve’s opening/closing speed (balanced internal parts).
5.The valve is durable, with the number of valve actions exceeding 1 million times.
Application
This valve is primarily used in the control systems of fluid transmission processes in industries such as air separation, petroleum, chemical, metallurgy, light industry, medicine, and power. It has a simple structure, small size, large flow rate, and low maintenance cost. It has effectively replaced other valves in the field of air separation due to its low leakage rate, sensitive action, and high cost performance.
