Design Specifications:
Function: Separation, Mixing
Valve Body: WCB
Internal Components: Stainless steel
Actuator: Stainless steel: Φ50, Φ63, Φ90, Aluminum Φ120
Sealing Material: NBR
Connection Method: Flange PN16
Air Pipe Connector: Φ50-Φ90: G½, Φ120: G1¼
Pressure Range: Under 6 bar air supply pressure
Valve Body: Maximum pressure 16 bar（WCB）
Internal Components: Stainless steel
Control Pressure:: 2-10 bar
Applicable media: Gas and liquid
Temperature Range: -10℃ to 90℃
Ambient Temperature: -10℃ to 60℃
Installation Position: As required, please select according to the direction of the fluid.
