Design Specifications:
Size: DN15-DN100 (1/2’’-4’’).
Connection Type: flange, other methods for customized consultation.
Valve body: WCB
Actuator: CF8,ALU
Seat seal: PTFE, RPTFE
Stem seal: PTFE,FKM,RPTFE
Piston seal: FKM,NBR
Nominal pressure (working pressure): 0-16bar (0-232Psi), vacuum as low as -0.9bar optional.
Control pressure: 2-10bar
Control medium: clean compressed air, lubricated or dry other and neutral gases, inert gas ≤60℃.
Outside temperature (environment): -10℃- 80℃.
Applicable media: water, neutral gas or liquid, alcohol, oil, fuel, steam, organic solvents, acid-base solutions, etc.
Medium temperature: -10℃- 180℃ (PTFE normal temperature type)
25℃- 220℃ (PTFE high temperature type)
Maximum viscosity: 600cst (mm²/s)
Valve leakage class: DIN EN 12266 Class A
Advantages：
◎The 200 series pneumatic metal two-way stop valve is equipped with a low-maintenance metal pneumatic actuator.
◎The valve stem seal adopts a self-adjusting design, with low maintenance requirements, and maintains excellent sealing performance even after long-term operation.
Application：
Especially suitable for high-temperature steam media and large-diameter pipelines.
