Technical Specifications
Control type: Double-acting free state, double-acting normally closed
Working pressure: 0-7bar (0-102Psi)
Control media: Clean compressed air or neutral gas, temperature ≤60℃.
Control pressure: 3-4.5bar(44-65Psi)
Valve body material: CF8,CF8M
Sealing material: PTFE
Applicable medium: Water, neutral gas or liquid, alcohol, oil, fuel, steam, organic solvents, acid and Acid-base solution, etc.
Medium temperature: -10℃~ 120℃
Ambient temperature: -10℃~ 80℃
Connection type: Threaded (BSP,BSPT,NPT)
Advantages
- It is widely used in filling machinery, especially for applications with viscous, pasty and even foamy fluids.
- Fast, accurate and stable filling.
- Delicate and compact, easy to arrange pipeline layout.
- Special nozzle structure and sealing design ensure no dripping leakage.
- Bottom chamfer structure of the filling nozzle self-locates and enables submerged filling.
- The head gourd shape design of the filling tube reduces weight and cost without sacrificing flow rate.
- With super strong suction function, it can timely recover the liquid sliding down the pipe wall without dripping.
